Facility managers may use these plans and integrate them with a Computer Aided Facilities Management (CAFM) software package.Īn Existing Conditions survey likewise is created post construction. These areas are then divided to determine the load factor which defines the rentable square footage (RSF) of tenant spaces. Property managers and brokers will have the plans analyzed to identify the square footage of tenant areas, common areas, and major vertical penetrations. Most often as-built floor plans are utilized by building owners to determine the gross and rentable areas during the due diligence period prior to sale completion. In the latter case as-built plans serve to create an up to date documentation of the interior layout of many tenant spaces which may have changed over the years. Post construction can be either immediately after the site is built or many years afterwards. Examples of deviations may be doors that were placed in a different location from what was specified in the construction documents to determining the actual size and shape of the building versus what was specified. The intention of these plans is to document any deviations from the architect’s original design. These plans are created after construction of the building is complete. The term as-built commonly refers to refers to 2D floor plans showing a limited amount of detail such as walls, doors, windows, millwork, and plumbing fixtures.
In the world of building measurement and area calculations the terms as-built floor plans and existing conditions plans sound as if they are interchangeable but are in fact are not. District's acceptance and approval of the "AS-BUILT" drawings are a necessary condition precedent to the release of the final retention.Home > Articles > "As-built" Vs. The Contractor shall verify that all changes in the work are included in the "AS- BUILT" drawings and deliver the complete set thereof to the Project Manager for review and approval within thirty (30) calendar days after District's notice of completion. Progress payments may be delayed or withheld until such time as the record set is brought up to date to the satisfaction of the Project Manager. All main runs, whether piping, conduit, duct work, drain lines, etc., shall be located in addition by dimension and elevation. Deviations from the drawings shall be shown in detail. Actual locations to scale shall be identified on the drawings for all runs of mechanical and electrical work, including all site utilities installed underground, in walls, floors, and furred spaces, or otherwise concealed. As changes occur, there will be included or marked on this record set on a daily basis if necessary to keep them up to date at all times. As-Built Drawings. The Contractor and all Subcontractors shall maintain on the work site a separate complete set of contract drawings which will be used solely for the purpose of recording changes made in any portion of the work during the course of construction, regardless of the reason for the change.
